19
9. SPECIFICATIONS
Product name OMRON SC-150 Scale with Bluetooth
®
Model
SC-150
HN-300T2-Z
Display 11 to 330 lb with an increment of 0.2 lb
(5 to 150 kg with an increment of 0.1 kg)
Weight accuracy 11.0 to 330.0 lb : ±(1 %+0.2 lb)
(5 to 150 kg : ±(1 %+0.1 kg))
Transmission method Bluetooth
®
Low Energy
Wireless
communication
Frequency range: 2.4 GHz (2400 - 2483.5 MHz)
Modulation: GFSK
Effective radiated power: <20 dBm
Durable Period 5 years
IP classification IP21
Power supply 4 “AAA” batteries
Battery life Approximately 3 months: using manganese batteries
Approximately 6 months: using alkaline batteries
(When each types of batteries are used in two measurement, two data
transfer a day at a room temperature of 73.4 °F (23 °C))
Operating conditions +41 to +104 °F (+5 to +40 °C), 30 to 85 % RH (non-condensing),
860 to 1060 hPa
Storage conditions -4 to +140 °F (-20 to +60 °C), 10 to 95 % RH (non-condensing)
Weight Approximately 3.3 lb (1.5 kg)
including batteries
External dimensions Approximately 10 5/8" (W) × 1 1/32" (H) × 11 27/64" (D)
270 (W) × 26.4 (H) × 290 (D) mm
Contents Digital weight scale, 4 “AAA” manganese batteries, instruction
manual, quick start guide
Applied part
Type BF (Plate)
Notes:
• These specifications are subject to change without notice.
• IP classification is degrees of protection provided by enclosures in accordance with IEC
60529. This device is protected against solid foreign objects of 0.5 inch (12.5 mm) diameter
and greater such as a finger. This device is protected against vertically falling water drops
which may cause issues during a normal operation.
