7-8
H Braking Resistor (Duty Cycle 3% ED)
Specifications Model
200-VAC Class
0.1 kW/0.2 kW 400 Ω 3G3IV-PERF150WJ401
0.4 kW/0.75 kW 200 Ω 3G3IV-PERF150WJ201
1.5 kW 100 Ω 3G3IV-PERF150WJ101
400-VAC Class
0.75 kW or less 750 Ω 3G3IV-PERF150WJ751
1.5 kW 400 Ω 3G3IV-PERF150WJ401
H Braking Resistor Unit (Duty Cycle 10% ED)
Specifications Model
200-VAC Class
0.4kW/0.75 kW 200 Ω, 70 W 3G3IV-PLKEB20P7
1.5 kW 100 Ω, 260 W 3G3IV-PLKEB21P5
400-VAC Class
0.75 kW or less 750 Ω, 70 W 3G3IV-PLKEB40P7
1.5 kW 400 Ω, 260 W 3G3IV-PLKEB41P5
H AC Reactor (for Three-Phase)
Specifications Model
Three-phase
0.1/0.2 kW 2 A 7.0 mH 3G3IV-PUZBAB2A7.0MH
200 V
0.4 kW 2.5 A 4.2 mH 3G3IV-PUZBAB2.5A4.2MH
0.75 kW 5 A 2.1 mH 3G3IV-PUZBAB5A2.1MH
1.5 kW 10 A 1.1 mH 3G3IV-PUZBAB10A1.1MH
Three-phase
0.2/0.4 kW 1.3 A 18.0 mH 3G3IV-PUZBAB1.3A18.0MH
400 V
0.75 kW 2.5 A 8.4 mH 3G3IV-PUZBAB2.5A8.4MH
1.5 kW 5 A 4.2 mH 3G3IV-PUZBAB5A4.2MH
H Simple Input Noise Filter
Specifications Model
Three-phase 200 V 0.1 to 0.75 kW 10 A 3G3EV-PLNFD2103DY
1.5 kW 15 A 3G3EV-PLNFD2153DY
Single-phase 200 V 0.1 to 0.2 kW 10 A 3G3EV-PLNFB2102DY
0.4 kW 15 A 3G3EV-PLNFB2152DY
0.75 kW 20 A 3G3EV-PLNFB2202DY
1.5 kW 30 A 3G3EV-PLNFB2302DY
Three-phase 400 V
0.2 to 0.75 kW 5 A 3G3EV-PLNFD4053DY
1.5 kW 10 A 3G3EV-PLNFD4103DY
H Output Noise Filter
Specifications Model
Three-phase 200 V 0.1 to 1.5 kW 10 A 3G3IV-PLF310KA
Three-phase 400 V 0.2 to 1.5 kW 10 A 3G3IV-PLF310KB
Appendix A Chapter 7
