H Digital Operator
Display
section
Operation
keys
Mode Key
Increment Key
RUN Key
Data display section
Monitor item indicators
In-service item indicators (green indicators)
These items can be monitored or set even
during operation.
Stopped item indicators (red indicators)
These items can be set only when the
Inverter is stopped.
Constant item indicators
Enter Key
Decrement Key
STOP/RESET Key (See note.)
Note For safety reasons, the reset will not work while a RUN command (forward or re-
verse) is in effect. Wait until the RUN command is OFF before resetting the
Inverter.
Overview Chapter 2
