www.dadehpardazan.ir 88594014-15
1-5
1-2 Nomenclature
H Panel
Protection cover (top and bottom)
Mounting hole
Heat sink
Digital Operator
Front cover
Terminals
Front cover fixing bracket
3G3FV Series
Introduction Chapter 1
