3-6SectionOffset and Gain Adjustment
57
Change the set value, using the Up Bit (bit 03 of word n+1) and the Down Bit
(bit 02 of word n+1).
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Bit
Up Bit Down Bit
While the Up Bit is ON, the resolution will be
increased by 1 every 0.5 seconds. After it has
been ON for 3 seconds, the resolution will be
increased by 1 every 0.1 seconds.
While the Down Bit is ON, the resolution will be
decreased by 1 every 0.5 seconds. After it has
been ON for 3 seconds, the resolution will be
decreased by 1 every 0.1 seconds.
Word n+1
SHIFT
CONT
#
1
B
0
A
1
B
0
A
2
C
MONTR
10102 c108
^OFF 0000
The bit will remain ON until the output becomes an appropriate value, at
which time, it will turn OFF.
PLAY
SET
10102 c108
ON FFFF
REC
RESET
10102 c108
OFF FFFF
5. Check the 0V/1V/4mA output, and then turn bit 04 (the Set Bit) of IR word
n+1 OFF, ON, and then OFF again.
SHIFT
CONT
#
1
B
0
A
1
B
0
A
4
E
MONTR
10104 10102 c108
^OFF ^ OFF FFFF
PLAY
SET
10104 10102 c108
ON ^ OFF FFFF
REC
RESET
10104 10102 c108
OFF ^ OFF FFFF
While the Offset Bit is ON, the offset value will be saved to the Unit’s EE-
PROM when the Set Bit turns ON.
