22
Model Temperature-
sensing element
Temperature
range
Code Conversion data (words n+1 through n+4, BCD)
C200H- K(CA) °C 0 to 200 00 FFFF 8020 to 8001 0000 to 0200 to 0220 FFFF
TS001/TS002 0 to 300 01 8030 to 8001 0000 to 0300 to 0330
0 to 400 02 8040 to 8001 0000 to 0400 to 0440
0 to 500 05 8050 to 8001 0000 to 0500 to 0550
0 to 600 06 8060 to 8001 0000 to 0600 to 0660
0 to 800 07 8080 to 8001 0000 to 0800 to 0880
0 to 1000 08 8100 to 8001 0000 to 1000 to 1100
°F 0 to 400 03 8040 to 8001 0000 to 0400 to 0440
0 to 500 04 8050 to 8001 0000 to 0500 to 0550
0 to 1000 09 8100 to 8001 0000 to 1000 to 1100
0 to 1600 10 8160 to 8001 0000 to 1600 to 1760
J (IC)/ °C 0 to 200 11 8020 to 8001 0000 to 0200 to 0220
L(Fe-Cu 0 to 300 12 8030 to 8001 0000 to 0300 to 0330
Ni) 0 to 400 13 8040 to 8001 0000 to 0400 to 0440
0 to 500 14 8050 to 8001 0000 to 0500 to 0550
C200H- Jpt100/ °C -50 to 50 15 8060 to 0000 to 0050 to 0060
TS101/TS102 pt100 -50 to 100 16 8065 to 0000 to 0100 to 0115
-20 to 80 17 8030 to 0000 to 0080 to 0090
0 to 100 18 8010 to 8001 0000 to 0100 to 0110
0 to 200 21 8020 to 8001 0000 to 0200 to 0220
0 to 300 22 8030 to 8001 0000 to 0300 to 0330
0 to 400 23 8040 to 8001 0000 to 0400 to 0440
°F -50 to 100 19 8065 to 0000 to 0100 to 0115
0 to 200 20 8020 to 8001 0000 to 0200 to 0220
0 to 400 24 8040 to 8001 0000 to 0400 to 0440
0 to 500 25 8050 to 8001 0000 to 0500 to 0550
Outside
range
-10% F.S.
Outside
range
F.S.
+10% F.S.
Temperature Data Display Section 4-2

Omron SYSMAC C200H Specifications

General

PLC Type	Modular
Operating Temperature	0 to 55°C
Programming Language	Ladder logic
Data Memory	512 words
Communication Ports	RS-232C
Humidity	10 to 90% RH (non-condensing)
Supply Voltage	100 to 120 VAC, 200 to 240 VAC, 24 VDC (depending on the power supply unit)
