Appendix DTable of Temperature-Sensing Elements
33
K Standard Thermoelectromotive Force
JIS-C 1602-1981 Unit: µV
Temperature (°C)
0 10 20 30 40 50 60 70 80 90 Temperature (°C)
0 0 397 798 1203 1611 2022 2436 2850 3266 3681 0
100 4095 4508 4919 5327 5733 6137 6539 6939 7338 7737 100
200 8137 8537 8938 9341 9745 10151 10560 10969 11381 11793 200
300 12207 12623 13039 13456 13874 14292 14712 15132 15552 15974 300
400 16395 16818 17241 17664 18088 18513 18938 19363 19788 20214 400
500 20640 21066 21493 21919 22346 22772 23198 23624 24050 24476 500
600 24902 25327 25751 26176 26599 27022 27445 27867 28288 28709 600
700 29128 29547 29965 30383 30799 31214 31629 32042 32455 32866 700
800 33277 33686 34095 34502 34909 35314 35718 36121 36524 36925 800
900 37325 37724 38122 38519 38915 39310 39703 40096 40488 40879 900
1000 41269 41657 42045 42432 42817 43202 43585 43968 44349 44729 1000
1100 45108 45486 45863 46238 46612 46985 47356 47726 48095 48462 1100
1200 48828 49192 49555 49916 50276 50633 50990 51344 51697 52049 1200
1300 52398 52747 53093 53439 53782 54125 54466 54807 --- --- 1300
J Standard Thermoelectromotive Force
JIS-C 1602-1981 Unit: µV
Temperature (°C)
0 10 20 30 40 50 60 70 80 90 Temperature (°C)
0 0 507 1019 1536 2058 2585 3115 3649 4186 4725 0
100 5268 5812 6359 6907 7457 8008 8560 9113 9667 10222 100
200 10777 11332 11887 12442 12998 13553 14108 14663 15217 15771 200
300 16325 16879 17432 17984 18537 19089 19640 20192 20743 21295 300
400 21846 22397 22949 23501 24054 24607 25161 25716 26272 26829 400
500 27388 37949 28511 29075 29642 30210 30782 31356 31933 32513 500
600 33096 33683 34273 34867 35464 36066 36671 37280 37893 38510 600
700 39130 39754 40382 41013 41647 42283 42922 43563 44207 44852 700
800 45498 46144 46790 47434 48076 48716 49354 49989 50621 51249 800
900 51875 52496 53115 53729 54351 54948 55553 56155 56753 57349 900
1000 57942 58533 59121 59708 60293 60876 61459 62039 62619 63199 1000
1100 63777 64355 64933 65510 66087 66664 67240 67815 68390 68964 1100
1200 69536 --- --- --- --- --- --- --- --- --- 1200
Note The temperature of standard contact should be 0°C.
