Table of Temperature-Sensing Elements Appendix D
34
L (Fe-CuNi) Standard Thermoelectromotive Force
DIN 1985 43710 Unit: µV
Temperature (°C)
0 10 20 30 40 50 60 70 80 90 Temperature (°C)
0 0 520 1050 1580 2110 2650 3190 3730 4270 4820 0
100 5370 5920 6470 7030 7590 8150 8710 9270 9830 10390 100
200 10950 11510 12070 12630 13190 13750 14310 14880 15440 16000 200
300 16560 17120 17680 18240 18800 19360 19920 20480 21040 21600 300
400 22160 22720 23290 23860 24430 25000 25570 26140 26710 27280 400
500 27850 28430 29010 29590 30170 30750 31330 31910 32490 33080 500
600 33670 34260 34850 35440 36040 36640 37250 37850 38470 39090 600
700 39720 40350 40980 41620 42270 42920 43570 44230 44890 45550 700
800 46220 46890 47570 48250 48940 49630 50320 51020 51720 52430 800
Note The temperature of standard contact should be 0°C.
Platinum Resistance Thermometer Bulb JPt 100 Ω Standard Thermoelectromotive
Force (R
0
= 100 Ω R
100
/R
0
= 1.3916)
JIS C1604 1989 Unit: Ω
Temperature (°C) –100 0 Temperature (°C) 0 100 200 300 400 500
0 59.57 100.00 0 100.00 139.16 177.13 213.93 249.56 284.02
–10 55.44 96.02 10 103.97 143.01 180.86 217.54 253.06 ---
–20 51.29 92.02 20 107.93 146.85 184.58 221.15 256.55 ---
–30 47.11 88.01 30 111.88 150.67 188.29 224.74 260.02 ---
–40 42.91 83.99 40 115.81 154.49 191.99 228.32 263.49 ---
–50 38.68 79.96 50 119.73 158.29 195.67 231.89 266.94 ---
–60 34.42 75.91 60 123.64 162.08 199.35 235.45 270.38 ---
–70 30.12 71.85 70 127.54 165.86 203.01 238.99 273.80 ---
–80 25.80 67.77 80 131.42 169.63 206.66 242.53 277.22 ---
–90 21.46 63.68 90 135.30 173.38 210.30 246.05 280.63 ---
–100 17.14 59.57 100 139.16 177.13 213.93 249.56 284.02 ---
Note The temperature of standard contact should be 0°C.
