349
Error Logs Section 11-4
0014 Hex Inner bus error Always 00 Hex Always 00 Hex Yes
0108 Hex Send not possible because
Unit is not detected
Event Send/Receive Errors
Commands:
Send source network address < 80
Bit 15: OFF
Bits 08 to 14: Send source network address
Bits 00 to 07: Send source node address
Send source network address ≥ 80
Bit 15: OFF
Bits 08 to 14: 00
Bits 00 to 07: Send source network address
Responses:
Send destination network address < 80
Bit 15: ON
Bits 08 to 14: Send destination network address
Bits 00 to 07: Send destination node address
Send destination network address ≥ 80
Bit 15: ON
Bits 08 to 14: 00
Bits 00 to 07: Send destination network address
No
010B Hex Send not possible due to
CPU Unit error
No
010D Hex Send not possible due to
remote address setting error
No
010E Hex Send not possible because
routing tables are not set
properly
No
0112 Hex Send not possible due to
header setting error
No
0117 Hex Internal reception buffer full No
0118 Hex Illegal packet discarded No
011B Hex Parity error 01 Hex: Port 1
02 Hex: Port 2
Always 00 Hex No
011C Hex Framing error No
011D Hex Overrun error No
011E Hex FCS check error No
021A Hex Setting table logic error Always 00 Hex 03 Hex: Routing tables
05 Hex: CPU Bus Unit/
Inner Board DM Area
No
0300 Hex Parameter packet discarded Same contents as event send/receive errors. No
0301 Hex Protocol macro operation
error
01 Hex: Port 1
02 Hex: Port 2
Protocol macro error code No
0302 Hex Illegal protocol packet dis-
carded.
01 Hex: Port 1
02 Hex: Port 2
Always 00 Hex No
0601 Hex Board/Unit error Check the operating environment. Yes
0602 Hex CPU Bus Unit/Inner Board
memory error
01 Hex: Read error
02 Hex: Write error
06 Hex: Error log
07 Hex: Protocol data
No
Error code Error contents Details Stored in
EEPROM
First byte Second byte
