Host Link FINS Command Master Appendix D
OPERATING MODE CHANGE (RUN)
(Sequence No. 764 (Hex 02FC))
This sequence sends command code 0401 hex to the specified Host Link Unit and changes the CPU Unit's
operating mode to MONITOR mode.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Offset Contents (data format) Data
+0
Number of send data words
(4 digits hex)
Always 0003 hex (3 decimal)
+1
Host Link unit
No.
(2 digits BCD)
Remote destina-
tion network
address (DNA)
(2 digits hex)
Host Link unit number: 00 to 31
Remote destination network address
(DNA): 00 to 7F hex
+2
Remote destina-
tion node
address (DA1)
(2 digits hex)
Remote destina-
tion unit address
(DA2)
(2 digits hex)
Remote destination node address
(DA1): 00 to FE hex
Remote destination unit address (DA2):
00 to FE hex
+0
+1
+2
First word of
send data
Number of send data words
Host Link unit number
Remote destination node
address
Remote destination
network address
Remote destination
unit address
Offset Contents (data format) Data
+0
Number of receive data words
(4 digits hex)
Always 0002 hex (2 decimal)
+1
End code (4 digits hex) The end code is stored in hexadecimal.
+0
+1
Receive data
storage words
Number of receive data words
End code
