Omron SYSMAC CJ1W-SCU21-V1 User Manual

445
Mitsubishi Computer Link Master (A-compatible 1C Frame, Model 1) Appendix E
• Sending Device Read/Write Commands Common to AnA/AnU CPU
Sequence
No.
Communications
sequence name
Computer Link
command
Device type Function
810 (032A) Device memory
batch read as word
data (all device
types except T/C)
QR (Device
memory batch
read as word
data)
Device other than
Timer/Counter
Reads the word data for the number of device
points starting from the specified device address
for the specified device type (except T, C) in the
Mitsubishi Computer Link Module with the speci-
fied station number (and the PLC number that
follows), converts the data into hexadecimal, and
stores it starting from the specified word + 2 in
the CS/CJ-series CPU Unit.
811 (032B) Device memory
batch read as word
data (T/C device
type)
Timer/Counter
(T, C)
Reads the word (PV) data for the number of
device points starting from the specified device
address for the specified device type (T, C) in the
Mitsubishi Computer Link Module with the speci-
fied station number (and the PLC number that
follows), converts the data into hexadecimal, and
stores it starting from the specified word + 2 in
the CS/CJ-series CPU Unit.
812 (032C) Device memory fill
as word data (all
device types except
T/C)
QW (Device
memory fill as
word data)
Device other than
Timer/Counter
Writes the word data starting from the specified
word + 7 in the CS/CJ-series CPU Unit to the
number of device points starting from the speci-
fied device address for the specified device type
(except T, C) in the Mitsubishi Computer Link
Module with the specified station number (and
the PLC number that follows).
813 (032D) Device memory fill
as word data (T/C
device type)
Timer/Counter
(T, C)
Writes the word (PV) data starting from the
specified word + 7 in the CS/CJ-series CPU Unit
to the number of device points starting from the
specified device address for the specified device
type (T, C) in the Mitsubishi Computer Link Mod-
ule with the specified station number (and the
PLC number that follows).
814 (032E) Device memory
batch read as bit
data (all device
types except T/C)
JR (Device mem-
ory batch read as
bit data)
Device other than
Timer/Counter
Reads the bit data for the number of device
points starting from the specified device address
for the specified device type (except T, C) in the
Mitsubishi Computer Link Module with the speci-
fied station number (and the PLC number that
follows), converts the data into hexadecimal, and
stores it starting from the specified word + 2 in
the CS/CJ-series CPU Unit.
815 (032F) Device memory
batch read as bit
data (T/C device
type)
Timer/Counter
(T, C)
Reads the bit (PV) data for the number of device
points starting from the specified device address
for the specified device type (T, C) in the Mitsub-
ishi Computer Link Module with the specified
station number (and the PLC number that fol-
lows), converts the data into hexadecimal, and
stores it starting from the specified word + 2 in
the CS/CJ-series CPU Unit.
816 (0330) Device memory fill
as bit data (all
device types except
T/C)
JW (Device
memory fill as bit
data)
Device other than
Timer/Counter
Writes the bit data starting from the specified
word + 7 in the CS/CJ-series CPU Unit to the
number of device points starting from the speci-
fied device address for the specified device type
(except T, C) in the Mitsubishi Computer Link
Module with the specified station number (and
the PLC number that follows).
817 (0331) Device memory fill
as bit data (T/C
device type)
Timer/Counter
(T, C)
Writes the bit (PV) data starting from the speci-
fied word + 7 in the CS/CJ-series CPU Unit to
the number of device points starting from the
specified device address for the specified device
type (T, C) in the Mitsubishi Computer Link Mod-
ule with the specified station number (and the
PLC number that follows).
