Omron SYSMAC CJ1W-SCU21-V1 User Manual

471
E5 @ K Digital Controller Read Protocol Appendix F
Receive Data Word Allocation (4th Operand of PMCR(260))
Read Dead Band (Sequence No. 007 (Hex 0007))
Reads the dead band and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Read Manual Reset Value (Sequence No. 008 (Hex 0008))
Reads the manual reset value and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0002
+1 Cooling coefficient (4 digits BCD) 0001 to 9999
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0002
+1 Dead band (4 digits BCD) A999 to 9999
F indicates a negative value and A indicates
–1.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0002
+1 Manual reset value (4 digits BCD) 0000 to 1000
Receive data
storage words
Number of receive data words
+0
+1
Cooling coefficient
First word of
send data
Number of send data words+0
+1
(Undefined) Unit No.
Receive data
storage words
Number of receive data words
+0
+1
Dead band
First word of send
data
Number of send data words+0
+1
(Undefined) Unit No.
Receive data
storage words
Number of receive data words
+0
+1
Manual reset value
