E5 @ K Digital Controller Write Protocol Appendix G
Write Input Digital Filter (Sequence No. 062 (Hex 003E))
Writes the input digital filter.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Alarm Hysteresis (Sequence No. 063 (Hex 003F))
Writes the alarm 1 hysteresis and alarm 2 hysteresis.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Input Shift Value (Sequence No. 064 (Hex 0040))
Writes the input shift upper limit and input shift lower limit.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0003 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
+2 Input digital filter (4 digits BCD) 0000 to 9999
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0004 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
+2 Alarm 1 hysteresis
(4 digits BCD)
0001 to 9999
+3 Alarm 2 hysteresis
(4 digits BCD)
0001 to 9999
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0004 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
+2 Input shift upper limit (4 digits BCD) 0000 to 9999
+3 Input shift lower limit (4 digits BCD) 0000 to 9999
First word of
send data
Number of send data words+0
+1
+2
(Undefined) Unit No.
Input digital filter
First word of
send data
Number of send data words
+0
+1
+2
+3
(Undefined) Unit No.
Alarm 1 hysteresis
Alarm 2 hysteresis
First word of
send data
Number of send data words
+0
+1
+2
+3
(Undefined) Unit No.
Input shift upper limit
Input shift lower limit
