E5 @ K Digital Controller Write Protocol Appendix G
Switch to Level 1 (Sequence No. 075 (Hex 004B))
Switches the setting level to level 1 (setup mode, extended mode). This sequence can be executed for multiple
units.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Software Reset (Sequence No. 076 (Hex 004C))
Resets the operation of the E5@K (equivalent to turning on the power supply). This sequence can be executed
for multiple units.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Note Communications with the E5@K are disabled for about five seconds after this sequence is executed.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
Number of units + 2
+1 Number of units (4 digits Hex) 0001 to 0008
+2 to 9 Unit No. (2 digits BCD) 00 to 31
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
Number of units + 2
+1 Number of units (4 digits Hex) 0001 to 0008
+2 to 9 Unit No. (2 digits BCD) 00 to 31
(Undefined)
Unit No.
First word of
send data
Number of send data words
+0
+1
+2
+3
+9
(Undefined)
Unit No.
Number of units
(Undefined)
Unit No.
~ ~
(max.)
(Undefined)
Unit No.
First word of
send data
Number of send data words
+0
+1
+2
+3
+9
(Undefined)
Unit No.
Number of units
(Undefined)
Unit No.
~ ~
(max.)
