E5ZE Temperature Controller Read Protocol Appendix H
Read Set Point (Sequence No. 100 (Hex 0064))
Reads the set points and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Read Process Value (Sequence No. 101 (Hex 0065))
Reads the process values and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0011 (0017 decimal)
+1 Channel 0
Set point (rightmost 4 digits)
(4 digits BCD)
Varies according to the temperature sensor
type. Refer to the manual for the E5ZE.
F indicates a negative value.
+2 Channel 0
Set point (leftmost 1 digit) (1 digit BCD)
•
•
•
+15 Channel 7
Set point (rightmost 4 digits)
(4 digits BCD)
Varies according to the temperature sensor
type. Refer the manual for the E5ZE.
F indicates a negative value.
+16 Channel 7
Set point (leftmost 1 digit) (1 digit BCD)
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
First word of
send data
Number of send data words+0
+1
(Undefined) Unit No.
Receive data
storage words
Number of receive data words
+0
+1
+2
+15
+16
Set point (rightmost 4 digits)
~ ~
Set point (leftmost 1 digit)
Set point (rightmost 4 digits)
Set point (leftmost 1 digit)
Channel 0
Channel 7
First word of send
data
Number of send data words+0
+1
(Undefined) Unit No.
