E5ZE Temperature Controller Read Protocol Appendix H
Switch Settings
This section shows the switch settings for using the E5ZE Temperature Controller Read Protocol.
Communications Parameter DIP Switch
Unit Number Switch
Factory defaults
Baud Rate DIP Switch
Pins Parameter RS-422 RS-485
3 and 4 Terminating
resistance
ON
OFF
1 and 2 RS-422 or RS-485
Factory defaults: All OFF
Pins 3 and 4: Terminating resistance
Pins 1 and 2: RS-422/RS-485
DTS-4
1 2 3 4
ON
ON
3 4
OFF
ON
3 4
OFF
OFF
3 4
OFF
OFF
3 4
OFF
OFF
1 2
ON
ON
1 2
Setting 0123456789ABCDEF
Unit No. 00 01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F
Baud rate
(bps)
19,200 9,600 4,800 2,400
Pins 1 and 2
Factory default: 9,600 bps
(pin 1 ON, pin 2 OFF)
ON
12345678
ON
1 2
ON
1 2
ON
1 2
ON
1 2
