Omron SYSMAC CJ1W-SCU21-V1 User Manual

515
E5ZE Temperature Controller Read Protocol Appendix H
Receive Data Word Allocation (4th Operand of PMCR(260))
Read Input Shift Value (Sequence No. 113 (Hex 0071))
Reads the input shift values and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Read Manual Reset Value (Sequence No. 114 (Hex 0072))
Reads the manual reset value and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0002
+1 Set code (4 digits BCD) 0000: unit of 1
0001: unit of 0.1
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0009
+1 Channel 0
Input shift value (4 digits BCD)
0000 to 0999
F indicates a negative number.
+2 Channel 1
Input shift value (4 digits BCD)
0000 to 0999
F indicates a negative number.
•
•
•
+8 Channel 7
Input shift value (4 digits BCD)
0000 to 0999
F indicates a negative number.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Receive data
storage words
Number of receive data words
+0
+1
Set code
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
Receive data
storage words
Number of receive data words+0
+1
+2
+8
Input shift value
~ ~
Input shift value
Input shift value
Channel 0
Channel 7
Channel 1
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
