517
E5ZE Temperature Controller Read Protocol Appendix H
Read Present Set Point (Sequence No. 116 (Hex 0074))
Reads the present set points during ramp operation and stores the results in the specified word.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Read Output Value Limit (Sequence No. 117 (Hex 0075))
Reads the output value limits and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
+15 Channel 7
Ramp value (3 digits BCD)
000 to 999
+16 Channel 7
Time unit (one ASCII character)
S: Seconds; M: Minutes; H: Hours
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0011 (0017 decimal)
+1 Channel 0
Present set point (rightmost 4 digits)
(4 digits BCD)
Varies according to the temperature sensor
type. Refer to the manual for the E5ZE.
F indicates a negative value.
+2 Channel 0
Present set point (leftmost 1 digit)
(1 digit BCD)
•
•
•
+15 Channel 7
Present set point (rightmost 4 digits)
(4 digits BCD)
Varies according to the temperature sensor
type. Refer to the manual for the E5ZE.
F indicates a negative value.
+16 Channel 7
Present set point (leftmost 1 digit)
(1 digit BCD)
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
Receive data
storage words
Number of receive data words
+0
+1
+2
+15
+16
Present set point (rightmost 4 digits)
~ ~
Present set point (leftmost 1 digit)
Present set point (rightmost 4 digits)
Present set point (leftmost 1 digit)
Channel 0
Channel 7
First word of
send data
Number of send data words+0
+1
(Undefined) Unit No.
