E5ZE Temperature Controller Write Protocol Appendix I
Write Hysteresis (Sequence No. 158 (Hex 009E))
Writes the hysteresis for control outputs for ON/OFF control.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Start Autotuning (Sequence No. 159 (Hex 009F))
Starts autotuning (AT).
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0012 (0018 decimal) (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel 0
Hysteresis (4 digits BCD)
0000 to 0999
+3 Channel 0
Cooling hysteresis (4 digits BCD)
0000 to 0999
+4 Channel 1
Hysteresis (4 digits BCD)
0000 to 0999
+5 Channel 1
Cooling hysteresis (4 digits BCD)
0000 to 0999
•
•
•
+16 Channel 7
Hysteresis (4 digits BCD)
0000 to 0999
+17 Channel 7
Cooling hysteresis (4 digits BCD)
0000 to 0999
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0003 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel (Channel) No. (1 digit BCD) 0 to 7
First word of
send data
Number of send data words
+0
+1
+2
+3
+4
+5
+16
+17
(Undefined) Unit No.
Hysteresis
~ ~
Cooling hysteresis
Hysteresis
Cooling hysteresis
Channel 0
Channel 7
Hysteresis
Cooling hysteresis
Channel 1
First word of
send data
Number of send data words+0
+1
+2
(Undefined) Unit No.
(Undefined)
Channel
