Omron SYSMAC CJ1W-SCU21-V1 User Manual

533
E5ZE Temperature Controller Write Protocol Appendix I
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Manual Reset Value (Sequence No. 163 (Hex 00A3))
Writes the manual reset values.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
000A (000A decimal) (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel 0
Input shift value (4 digits BCD)
0000 to 0999
+3 Channel 1
Input shift value (4 digits BCD)
0000 to 0999
+4 Channel 2
Input shift value (4 digits BCD)
0000 to 0999
•
•
•
+8 Channel 6
Input shift value (4 digits BCD)
0000 to 0999
+9 Channel 7
Input shift value (4 digits BCD)
0000 to 0999
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
000A (0010 decimal) (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel 0
Manual reset value
(4 digits BCD)
0000 to 1000
+3 Channel 1
Manual reset value
(4 digits BCD)
0000 to 1000
+4 Channel 2
Manual reset value
(4 digits BCD)
0000 to 1000
•
•
•
+8 Channel 6
Manual reset value
(4 digits BCD)
0000 to 1000
+9 Channel 7
Manual reset value
(4 digits BCD)
0000 to 1000
First word of
send data
Number of send data words
+0
+1
+2
+3
+4
+5
+6
+7
+8
+9
(Undefined) Unit No.
Manual reset value
Manual reset value
Channel 0
Channel 1
Manual reset value
Channel 2
Manual reset value
Channel 3
Manual reset value
Channel 4
Manual reset value
Channel 5
Manual reset value
Channel 6
Manual reset value
Channel 7
