E5 @ J Temperature Controller Protocol Appendix J
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Input Shift Value (Sequence No. 207 (Hex 00CF))
Writes the input shift value.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
Number of units × 4 + 2
+1 Number of units (4 digits Hex) 0001 to 001F (1 to 31 decimal)
+2 1st unit Unit No. (2 digits BCD) 00 to 31
+3 1st unit
Proportional band (4 digits BCD)
0000 to 9999
+4 1st unit
Integral time (4 digits BCD)
0000 to 9999
+5 1st unit
Derivative time (4 digits BCD)
0000 to 9999
+6 2nd unit
Unit No. (2 digits BCD)
00 to 31
•
•
•
+125
(max.)
31th unit
Derivative time (4 digits BCD)
0000 to 9999
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0003 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
+2 Input shift value (4 digits BCD) 0000 to 9999
First word of
send data
Number of send data words+0
+1
+2
(Undefined) Unit No.
Input shift value
