556
E5 @ J Temperature Controller Protocol Appendix J
Receive Data Word Allocation (4th Operand of PMCR(260))
General-purpose Write (Sequence No. 216 (Hex 00D8))
Writes the parameter specified by setting a header code.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
General-purpose Read (Sequence No. 217 (Hex 00D9))
Reads the parameter specified by setting a header
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0003
+1 Status (2 digits Hex) 00 to 99
+2 Alarm 1 type (1 digit Hex)
Alarm 2 type (1 digit Hex)
Input type (1 digit BCD)
0 to 9
0 to 9
0 to 9
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0005 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
+2 Header code (two ASCII characters) Header codes that can be set
MB, WS, W%, WW, WB, WN, WV
+3 Data code (2 digits BCD) 01 to 02
+4 Write data (4 digits BCD) 0000 to 9999
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0004 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
+2 Header code (two ASCII characters) Header codes that can be set
RS, R%, RW, RB, RN, RV, RO
+3 Data code (2 digits BCD) 01 to 02
Receive data
storage words
Number of receive data words+0
+1
+2
Status
Alarm 1 type
(Undefined)
Input type(Undefined)
Alarm 2 type
First word of send
data
Number of send data words+0
+1
+2
+3
+4
(Undefined) Unit No.
Header code (ASC)
(Undefined) Data code
Send data
First word of
send data
Number of send data words+0
+1
+2
+3
(Undefined) Unit No.
Header code (ASC)
(Undefined) Data code
