Intelligent Signal Processor Protocol Appendix L
Note 1. Special specifications are required to use communications + comparison output.
2. Special specifications are required to use communications + comparison output for the K3TR and
K3TC. The operands HH, H, L, and LL are for the K3TR, and the operands O5, O4, O3, O2, and O1
are for the K3TC.
3. Not available for the K3TC.
4. The hexadecimal equivalents of sequences numbers are given in parentheses.
319 (013F) Read set value H (contin-
uous units)
Reads the set value H. Yes Yes 1
320 (0140) Read set value L (contin-
uous units)
Reads the set value L. Yes Yes 1
321 (0141) Read set value LL (con-
tinuous units)
Reads the set value LL. Yes Yes 1
322 (0142) Read set value with bank
(by unit number)
Reads set value of a bank which is
not in use (K3TR: HH to LL, K3TC:
O1 to O5).
Ye s Ye s 2
323 (0143) Read set value HH with
bank (continuous units)
Reads the set value HH of a bank
which is not in use.
Ye s Ye s 1
324 (0144) Read set value H with
bank (continuous units)
Reads the set value H of a bank
which is not in use.
Ye s Ye s 1
325 (0145) Read set value L with
bank (continuous units)
Reads the set value L of a bank
which is not in use.
Ye s Ye s 1
326 (0146) Read set value LL with
bank (continuous units)
Reads the set value LL of a bank
which is not in use.
Ye s Ye s 1
327 (0147) Read set value O5 with
bank (continuous units)
Reads the set value O5 of a bank
which is not in use.
Ye s Ye s 1
328 (0148) Read set value O4 with
bank (continuous units)
Reads the set value O4 of a bank
which is not in use.
Ye s Ye s 1
329 (0149) Read set value O3 with
bank (continuous units)
Reads the set value O3 of a bank
which is not in use.
Ye s Ye s 1
330 (014A) Read set value O2 with
bank (continuous units)
Reads the set value O2 of a bank
which is not in use.
Ye s Ye s 1
331 (014B) Read set value O1 with
bank (continuous units)
Reads the set value O1 of a bank
which is not in use.
Ye s Ye s 1
332 (014C) Read holding data (by
unit number)
Reads the peak/bottom data (max-
imum, minimum).
Ye s Ye s 3
333 (014D) Read holding data PH
(continuous units)
Reads the peak data (maximum). Yes Yes 3
334 (014E) Read holding data BH
(continuous units)
Reads the bottom data (minimum). Yes Yes 3
335 (014F) Read display value (PV)
(by unit number)
Reads the display value (PV). Yes Yes
336 (0150) Read display value (PV)
(continuous units)
Reads the display value (PV). Yes Yes
337 (0151) Read model (by unit
number)
Reads the model data. Yes Yes
338 (0152) Read model (continuous
units)
Reads the model data. Yes Yes
339 (0153) General-purpose com-
mand
Send specified data or receives
specified data and writes it to the
receive data words.
Ye s Ye s
Sequence
No.
Communications
sequence name
Function Ladder interface Notes
Send word
allocation
Receive word
allocation
