606
K3T @ Intelligent Signal Processor Protocol Appendix L
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Set Value H (Continuous Units) (Sequence No. 304 (Hex
0130))
This sequence writes set value H for continuous units. The word allocation is identical to that of sequence No.
303 (Write Set Value HH (Continuous Units)).
Write Set Value L (Continuous Units) (Sequence No. 305 (Hex
0131))
This sequence writes set value L for continuous units. The word allocation is identical to that of sequence No.
303 (Write Set Value HH (Continuous Units)).
Write Set Value LL (Continuous Units) (Sequence No. 306 (Hex
0132))
This sequence writes set value LL for continuous units. The word allocation is identical to that of sequence No.
303 (Write Set Value HH (Continuous Units)).
Write Set Value with Bank (by Unit Number) (Sequence No. 307
(Hex 0133))
This sequence writes set value of a bank which is not in use (K3TR: HH to LL, K3TC:O1 to O5).
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0004 to 0042 (4 to 66 decimal)
+1 Number of units
(4 digits Hex)
0001 to 0020 (1 to 32 decimal)
+2 to +3 Set value
(5 digits BCD)
•
•
•
+64 to
+65
Set value
(5 digits BCD)
Same as above
00000 to 99999
Negative sign: F (5th digit in BCD)
Example 12345
+2
+3
2345
0001
Example –1234
+2
+3
1234
000F
