619
K3T @ Intelligent Signal Processor Protocol Appendix L
Receive Data Word Allocation (4th Operand of PMCR(260))
Model Data Read (Continuous Units) (Sequence No. 338 (Hex
0152))
This sequence reads model data for continuous units.
Send Data Word Allocation (3rd Operand of PMCR(260))
Note The number of Units can be up to 25 maximum.
Offset Contents (data format) Data
+0 Number of receive data
words (4 digits Hex)
0006 to 007E (6 to 126 decimal)
+1 to
+ 2
Input specifications (ASCII 3
characters)
544131 (“TA1”) (K3TH)
544231 (“TB1”) (K3TH)
564432 (“VD2”) (K3TX)
414432 (“AD2”) (K3TX)
564132 (“VA2”) (K3TX)
414132 (“AA2”) (K3TX)
524231 (“RB1”) (K3TR, K3TC)
+2 Display specifications (ASCII
1 character)
41 (“A”) (common)
42 (“B”) (K3TH, K3TX)
43 (“C”) (K3TR, K3TC)
+3 Output specifications (ASCII
2 characters)
5331 (“S1”) (RS-232C)
5332 (“S2”) (RS-485)
5333 (“S3”) (RS-422)
5335 (“S5”) (RS-485 + comparison output)
5336 (“S6”) (RS-422 + comparison output)
+4 Input contents
(ASCII 2 characters)
Leftmost digit: 30 (“0”) to 31 (“1”)
Rightmost digit: 31 (“1”) to 45 (“E”)
+5 Operation mode
(ASCII 2 characters)
3030 (“00”) (K3TH, K3TX)
3031 (“00”) to 3133 (“12”) (K3TR)
5542 (“UB”) (K3TC)
5543 (“UC”) (K3TC)
•
•
•
+125 Operation mode
(ASCII 2 characters)
Same as above
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002
+1 Number of units
(4 digits Hex)
0001 to 0019 (1 to 25 decimal)
+0
+1
+2
+3
+4
+5
+121
+122
+123
+124
+125
Operation mode
Input specifications
Display specifications
Input specifications
Output specifications
Input contents
Operation mode
Input specifications
Display specifications
Number of receive data wordsReceive data
storage words
~ ~
Input specifications
Output specifications
Input contents
Number of units
+0
+1
Number of send data words
First word of
send data
