643
3Z4L Laser Micrometer Protocol Appendix N
Program Number Set (3000-series) (Sequence No. 406 (Hex
0196))
This sequence switches the program number to a specified number.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Note Retry processing is not performed for this sequence.
Measurement Condition Set (3000-series) (Sequence No. 407
(Hex 0197))
This sequence sets measurement conditions. Conditions to be set can be selected by setting Yes/No flags.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Program number (1 digit BCD) 0 to 9
First word of send
data
Number of send data words
+0
+1
(Undefined)
Program number (1 digit BCD)
To Next Page
