3Z4L Laser Micrometer Protocol Appendix N
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0054 (fixed)
+1 Unused Undefined
+2 to +4 Segment number
(ASCII 6 characters)
Combination of 31(‘1’) to 36(‘6’), 20(‘ ’)
+5 Measurement interval num-
ber (1 digit BCD)
1 to 4
+6 Lower limit value (decimal
portion)
(4 digits BCD)
0000 to 9999
+7 Lower limit value (Integer
portion)
(3 digits BCD)
000 to 999
+8 Lower limit value (Sign)
(ASCII 1 character)
if +: 20(‘ ’)
if –: 2D(‘–’)
+9 to
+11
Upper limit value Same as lower limit values
+12 to
+14
Multistep selection limit
value (L1)
Same as lower limit values
+15 to
+17
Multistep selection limit
value (L2)
Same as lower limit values
+18 to
+20
Multistep selection limit
value (L3)
Same as lower limit values
+21 to
+23
Multistep selection limit
value (L4)
Same as lower limit values
+24 to
+26
Multistep selection limit
value (L5)
Same as lower limit values
+27 to
+29
Multistep selection limit
value (L6)
Same as lower limit values
+30 to
+32
Reference value Same as lower limit values
+30
+31
+32
+33
+34
+35
+36
+37
+38
+39
+40
+41
+42
+43
+44
+45
+46
+47
+48
+49
+50
+51
+52
+53
(Undefined)
Integer portion
Sign
(Undefined)
(Undefined)
(Undefined)
Decimal portion
(Undefined) Integer portion
Sign
(Undefined)
(Undefined)
(Undefined)
(Undefined)
(Undefined)
(Unused)
(Unused)
0
0
0
0
0
0
0
0
Decimal portion
(PRT)
(SMP)
Reference value (REF)
Analog output scale number (SCL)
Offset classification (OF)
Offset value
Data output conditions (PR)
Sample measurement classification
Schedule output timer
Sample measurement pulse
Setting Yes/No flags
4 5 6 7
0 1 2 3
2 D 0 0
+6
+7
+8
Example –123.4567
