Visual Inspection System Protocol Appendix O
Send Data Word Allocation (3rd Operand of PMCR(260))
None.
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Binary Level Modification (F200/300) (Sequence No. 482 (Hex
01E2))
This sequence modifies the binary levels (upper limit and lower limit values) of a designated output No. (F200)
or window number No. (F300).
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Note Enter values so that the upper limit
≥ lower limit.
Reset (F200/300) (Sequence No. 483 (Hex 01E3))
This sequence resets the F200/F300 (to starting status).
Send Data Word Allocation (3rd Operand of PMCR(260))
None.
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Scene Switching (Decrease by 1) (Sequence No. 490 (Hex
01EA))
This sequence decreases the scene No. by 1.
Send Data Word Allocation (3rd Operand of PMCR(260))
None.
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Scene Switching (Increase by 1) (Sequence No. 491 (Hex 01EB))
This sequence increases the scene No. by 1.
Send Data Word Allocation (3rd Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0004
+1 Window No. (1 digit BCD) 0 to 7
+2 Upper limit value (3 digits BCD) 000 to 255
+3 Lower limit value (3 digits BCD) 000 to 255
First word of
send data
Number of send data words
+0
+1
+2
+3
(Undefined)
Upper limit value
(Undefined)
Lower limit value
(Undefined)
Window No. or Output No.
