V600/V620 ID Controller Protocol Appendix P
Write (Hex/4) (Sequence No. 524 (Hex 020C))
This sequence is used when the number of Heads to be written to the Carrier is 4. Up to 24 digits of data can
be written for each Read/Write Head.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0007 to 0060 (7 to 96 decimal)
+1 Number of Heads
(4 digits Hex)
0001 to 0004
+(28(N–1)+2) Unit No. (2 digits BCD) Arbitrary (However, there is a limit for the max-
imum Unit No. depending on the model)
+(28(N–1)+3) R/W Head CH No.
(1 digit BCD)
R/W Head CH 1 designation: 1
R/W Head CH 2 designation: 2
The CD1D must be set to 1.
+(28(N–1)+4) Leading address No.
(4 digits Hex)
0000 to FFFF
+(28(N–1)+5) Number of write digits
(4 digits Hex)
0002 to 0018 (2 to 24 decimal)
+(28(N–1)+6) to
(28(N–1)+11)
Write data (Hex) Input in hexadecimal code
Up to 24 digits (max.) can be set
N: Number of Heads
First word of send
data
Number of Heads
+0
+1
+2
+3
+4
+5
+6
+11
+12
+29
+30
+31
+32
+33
+34
+39
+86
+87
+88
+89
+90
+95
CH 1
Number of send data words
(Undefined)
Unit No.
(Undefined)
Head CH No.
Leading address No.
CH 2
Write data
~ ~
Write data
(Undefined)
Unit No.
(Undefined)
Head CH No.
Leading address No.
Write data
Write data
~ ~
(Undefined)
Unit No.
(Undefined)
Head CH No.
Leading address No.
Number of write digits
Write data
~ ~
Write data
CH 4
Not used
~ ~
Not used
~ ~
Number of write digits
Number of write digits
