Step Run and Break Section 4-3
108
Register IO Break Condition
Here shows the registration procedure for I/O break condition.
1,2,3…
1. Display [Register IO Break Condition] by [CX-Simulator Debug Console] |
[IO Break Condition] and click the [Add] in the list (AND LIST/OR LIST) for
registering I/O break condition to register I/O break condition. Display the
[Register IO Break Condition] window.
2. Select either I/O Condition or Word Condition and input the type of the
target I/O memory area, condition operator (only Word Condition), and the
value followed by the [OK] button.
Condition expression:
IO0.0=ON
