Comparison of the CX-Simulator and SYSMAC CS/CJ–series PLCs Section 1-7
21
Item CS/CJ-series PLC CX-Simulator
Sequence Input Equivalent
Sequence Output Equivalent
Sequence Control Equivalent
Timer/Counter Equivalent
Comparison Equivalent
Data Movement Equivalent
Data Shift Equivalent
Incre-
ment/Decrement
Equivalent
Symbol Math Equivalent
Conversion Equivalent
Logic Equivalent
Special Math Equivalent
Floating-point
Math
Equivalent (A rounding error may occur.)
Table Data Proc-
essing
Equivalent
Data Control Equivalent (Nothing is executed for PID.)
Subroutines Equivalent
Interrupt Control Equivalent
Step Equivalent
Basic I/O Unit IORF, IORD, and IOWR available. Nothing is executed for the left
instructions.
Serial Communi-
cations
PMCR available.
TXD, RXD, and STUP available.
Nothing is executed for PMCR.
TXD, RXD, and STUP operate
differently depending on commu-
nications parameters.
Network SEND, RECV, and CMND available. SEND, RECV, and CMND operate
differently depending on commu-
nications parameters.
File Memory Equivalent
Display Equivalent (Messages of Programming Console are displayed on the screen.)
High-Speed
Counter Pulse
Control Instruc-
tions (CJ1M only)
INI, SPED, PRV, CTBL, PULS, ACC, PLS2,
ORG, and PWM instructions
Nothing is executed for the in-
structions listed at the left.
Clock Equivalent (The setting of day of the week is modified automatically according to the
calendar of the computer.)
Debugging Equivalent
Failure
Diagnosis
Equivalent (Messages of Programming Console are displayed on the screen.)
Special Equivalent
Block
Programming
Equivalent
Text String Proc-
essing
Equivalent
Instructions
Task Control Equivalent
Note
TIM/TIMH (Timer No. 2,048 to 4,095), TTIM, TIML, MTIM, and FPD will not operate
normally when the cycle time is 100 ms or longer. Make sure that the cycle time is
different from that of the CS/CJ-series CPU Unit if set as the computer cycle time.
