A - 23
Appendices
NX-series Communications Interface Units User’s Manual (W540)
A-3 List of NX Objects
A
A-3-3 NX Objects for the NX-CIF210
a) The following table gives the Output Sub Info when the Change Number of Characters to Deter-
mine the End control command is specified.
b) The following table gives the Output Sub Info when the Change Communications Setup control
command
is spec
ified. If any of the set values is out of range, 0003 hex (setting out-of-range
error) is returned in the Input Sub Info from the CIF Unit.
Bit Item name Description
00 to 15 Number of Characters to
Dete
rmine the End
The value specified for the number of characters to determine the
end.
*1
Setting range: 0000 to 2710 hex (0 to 10,000 decimal)
The number of characters to determin
e th
e end is not set if 0000
hex is specified.
Unit: 0.1 character
*1. For example, if 0064 hex (100 decimal) is specified, the number of characters to determine the end is
10.
Bit Item name Description
00 to 03 Baud Rate [bps] 0 hex: No change
1 hex: 1,200
2 hex: 2,400
3 hex: 4,800
4 hex: 9,600
5 hex: 19,200
6 hex: 38,400
7 hex: 57,600
8 hex: 115,200
9 hex: 230,400
04 to 05 Data Length [bits] 0 hex: No change
1 hex: 7
2 hex: 8
06 to 07 Parity 0 hex: No change
1 hex: No parity
2 hex: Even
3 hex: Odd
08 to 09 Stop Bits [bits] 0 hex: No change
1 hex: 2
2 hex: 1
10 to 11 Flow Control Method 0 hex: No change
1 hex: No flow control
2 hex: RS/CS flow control
3 hex: Xon/Xoff control
12 to 13
Flow Control Target
*1
*1. This item is not valid when no flow control is set.
0 hex: No change
1 hex: Send/receive
2 hex: Send only
3 hex: Receive only
14 to 15
Initial RS Signal Value
*2
*2. This is the value of the RS signal when communications are in the Operational state or immediately
after restarting the port. This item is invalid when the flow control method is set to RS/CS flow control,
and the initial RS signal value will always be ON. If the Initial RS Signal Value is set to OFF, use the RS
Signal ON control command to turn ON the RS signal.
0 hex: No change
1 hex: ON
2 hex: OFF
To Next Page
