NX-series Communications Interface Units User’s Manual (W540)
This section lists other objects.
• The following table gives the meanings of the set valu
es for the Ch1 Transmission Buffering
Enable/Disable Setting and Ch2 Transmission Buffering Enable/Disable Setting.
• The following table gives the meanings of the set values for the Ch1 Baud Rate and Ch2 Baud Rate.
Other Objects
Index
(hex)
Subindex
(hex)
Object name Default Data range Unit
Data
type
Access
I/O allo-
cation
Data
attri-
bute
5000 --- Transmission Buffer-
ing Enable/Disable
Setting
--- --- --- --- --- --- ---
01 Ch1 Transmission
Buffering Enable/Dis-
able Setting
1 0 or 1 --- USINT RW No Y
02 Ch2 Transmission
Buffering Enable/Dis-
able Setting
1 0 or 1 --- USINT RW No Y
Set value Description
0 Disabled
1 Enabled
Index
(hex)
Subindex
(hex)
Object name Default Data range Unit
Data
type
Access
I/O allo-
cation
Data
attri-
bute
5001 --- Baud Rate --- --- --- --- --- --- ---
01 Ch1 Baud Rate 3 0 to 8 --- USINT RW No Y
02 Ch2 Baud Rate 3 0 to 8 --- USINT RW No Y
Set value Description
0 1,200 bps
1 2,400 bps
2 4,800 bps
3 9,600 bps
4 19,200 bps
5 38,400 bps
6 57,600 bps
7 115,200 bps
8 230,400 bps
