Omron SYSMAC NX-CIF105

To Next Page

To Previous Page

4 Installation and Wiring

4 - 12

NX-series Communications Interface Units User’s Manual (W540)

3 Bundle the wires with a cable tie and secure them to the screwless clamping terminal block.

Secure wires within the range of 30 mm from the screwless cla

mping terminal block.

30 mm
