Omron W4S1-0 Series User Manual

Rev. 1.0
12
2.3.2. Transferring the Safety Application Data
Transfer the safety application data to the Safety Network Controller (NX-CSGxxx)
1
From the Multiview Explorer, select
new_Controller_0
2
From Project -> Build Controller to check
for errors and compile the project
3
From Controller -> Online to go online to
the safety network controller
4
From Controller -> Synchronize.
The Synchronization Dialog Box is
displayed.
Check that the data to transfer (select
NX).
Select Transfer To Controller to
download the application.
5
During synchronization confirmation
and warning dialog boxes will be
displayed. Read and choose the option
accordingly.
Check the message “The
Synchronization process successfully
finished.” which indicate the
synchronization is completed.
Select Close.

Omron W4S1-0 Series Specifications

General

Brand	Omron
Model	W4S1-0 Series
Category	I/O Systems
Language	English
