WL-N/WLG
General-purpose Switches
Environment-resistant Switches
Spatter-prevention Switches
Long-life Switches Accessories Safety Precautions
35
High-sensitivity and High-precision Models
(1) Actuator and Property Specifications
(2) Environment-resistant Specifications
(3) Built-in Switch Specifications
(4) Temperature Specifications
* (2) Environment-resistant Specifications Cannot be combined with
symbols RP or P1.
(5) Wiring and Built-in Switch Specifications
(6) Indicator Specifications
* (2) Environment-resistant Specifications Symbols: RP, P1
(4) Temperature Specifications Cannot be combined with
symbols TH or TC.
(7) Lamp Wiring
WLG@ - @@@@@@
(1) (2) (3) (4) (5) (6) (7)
Code Actuator
Pretravel
(PT)
2
Roller lever
Roller lever: R38 mm
High-sensitivity Models
10°
CA2
Roller lever: R38 mm
High-precision Models
5°
12
Adjustable Roller Lever (R25 to 89
mm) high-sensitivity model
10°
L Flexible rod
Adjustable rod lever (25 to 140
mm) high-sensitivity model
10°
Code Specifications
None Standard Built-in Switch
RP Corrosion-resistant type
P1 Weather-resistant type
Code Specifications
None Standard Built-in Switch
55 Airtight built-in switch
Code Specifications
None Ambient operating temperature -10 to +80°C
TH Ambient operating temperature (5 to 120°C) (Heat-resistant type) *
TC
Ambient operating temperature (-40 to +40°C) (Cold-resistant
type) *
+ 2°
- 1°
- 2°
0°
+ 2°
- 1°
+ 2°
- 1°
Code
Terminal
shape
Built-in
switch
specification
Mold specifications
None
Screw
terminals
(Conduit size:
G
1
/2)
Standard
None
139
Direct-wire
cable
Molded conduit opening and cover.
(The cover cannot be removed.)
140
Direct-wire
cable
Airtight built-
in switch
Molded conduit opening, cover,
and cover mounting screws. (The
cover cannot be removed.)
141
Molded conduit opening, cover,
cover mounting screws, and head.
(The cover cannot be removed,
and head direction cannot be
changed.)
RP60
Molded conduit opening, cover,
cover mounting screws, and head
mounting screws. (The cover can-
not be removed, and head direc-
tion cannot be changed.) Fluorine
rubber is used for all rubber parts.
Code Specifications
None No indicator
LD LED (10 to 115 V AC/DC) *
LE Neon lamp (125 to 250 V AC) *
Code Specifications
None No indicator
2 NC wiring (Lit when operating)
3 NO wiring (Lit when not operating)
