Omron WL-N - Roller Lever

WL-N/WLG
36
Ordering Information
Roller Lever
* Ask your OMRON representative for details on Two-core switches.
Apperance Actuator Terminal shape
Built-in switch specification/
Temperature Specifications
Pretravel
(PT)
Without operation
indicator
With operation indicator
Indicator LED
Model
Wiring
Specifications
Model
Roller lever:
R38 mm
Screw terminals
(Conduit size: G
1
/ 2 )
Heat-resistant type
15±5° WLCA2-TH-N --- ---
25±5° WLCA2-2TH-N --- ---
20° max. WLCA2-2NTH-N --- ---
10° WLG2-TH --- ---
5° WLGCA2-TH --- ---
Cold-resistant type
15±5° WLCA2-TC-N --- ---
25±5° WLCA2-2TC-N --- ---
20° max. WLCA2-2NTC-N --- ---
10° WLG2-TC --- ---
5° WLGCA2-TC --- ---
Corrosion-resistant type
15±5° WLCA2-RP-N --- ---
10° WLG2-RP --- ---
5° WLGCA2-RP --- ---
Weather-resistant type
15±5° WLCA2-P1-N --- ---
10° WLG2-P1 --- ---
Direct-wire cable
Coolant-resistant type
15±5° WLCA2-RP60-N
NC wiring WLCA2-RP60LD2-N
NO wiring WLCA2-RP60LD3-N
25±5° WLCA2-2RP60-N
NC wiring WLCA2-2RP60LD2-N
NO wiring WLCA2-2RP60LD3-N
10° WLG2-RP60
NC wiring WLG2-RP60LD2
NO wiring WLG2-RP60LD3
5° WLGCA2-RP60
NC wiring WLGCA2-RP60LD2
NO wiring WLGCA2-RP60LD3
Corrosion-resistant type 15±5° WLCA2-RP40-N --- ---
Molded terminal -139
15±5° WLCA2-139-N
NC wiring WLCA2-139LD2-N
NO wiring WLCA2-139LD3-N
25±5° WLCA2-2139-N
NC wiring WLCA2-2139LD2-N
NO wiring WLCA2-2139LD3-N
20° max. WLCA2-2N139-N --- ---
10° WLG2-139 NO wiring WLG2-139LD3
5° WLGCA2-139
NC wiring WLGCA2-139LD2
NO wiring WLGCA2-139LD3
Molded terminal -140
15±5° WLCA2-140-N --- ---
20° max. WLCA2-2N140-N --- ---
10° WLG2-140
NC wiring WLG2-140LD2 *
NO wiring WLG2-140LD3 *
Molded terminal -141
15±5° WLCA2-141-N
NC wiring WLCA2-141LD2-N
NO wiring WLCA2-141LD3-N
10° WLG2-141
NC wiring WLG2-141LD2
NO wiring WLG2-141LD3
5° WLGCA2-141 NO wiring WLGCA2-141LD3
+2°
-1
+2°
0°
+2°
-1°
+2°
0°
+2°
-1°
+2°
0°
+2°
-1°
+2°
-1
+2°
0
+2°
-1°
+2°
0
+2°
-1°
+2°
-1°
+2°
0
