Omron WL-N - Page 5

WL-N/WLG
General-purpose Switches
Environment-resistant Switches
Spatter-prevention Switches
Long-life Switches Accessories Safety Precautions
37
Plunger
Apperance Actuator Terminal shape
Built-in switch specification/
Temperature Specifications
Pretravel
(PT)
Without operation
indicator
Model
Adjustable
roller lever
(R25 to 89
mm)
Screw terminals
(Conduit size: G
1
/ 2 )
Heat-resistant type
15±5° WLCA12-TH-N
25±5° WLCA12-2TH-N
20° max. WLCA12-2NTH-N
10° WLG12-TH
Cold-resistant type
15±5° WLCA12-TC-N
25±5° WLCA12-2TC-N
20° max. WLCA12-2NTC-N
10° WLG12-TC
Corrosion-resistant type
15±5° WLCA12-RP-N
10° WLG12-RP
Weather-resistant type
15±5° WLCA12-P1-N
10° WLG12-P1
Direct-wire cable
Coolant-resistant type 15±5° WLCA12-RP60-N
Molded terminal -139 15±5° WLCA12-139-N
Molded terminal -140 15±5° WLCA12-140-N
Apperance Actuator Terminal shape
Built-in switch specification/
Temperature Specifications
Pretravel (PT)
Without operation indicator
Model
Sealed top-roller plunger
Screw terminals
(Conduit size: G
1
/2)
Heat-resistant type
1.7 mm max.
WLD28-TH-N
Cold-resistant type WLD28-TC-N
Corrosion-resistant type WLD28-RP-N
Direct-wire cable
Coolant-resistant type WLD28-RP60-N
Molded terminal -139 WLD28-139-N
Molded terminal -140 WLD28-140-N
Top-roller plunger
Screw terminals
(Conduit size: G
1
/2)
Heat-resistant type WLD2-TH-N
Direct-wire cable
Coolant-resistant type WLD2-RP60-N
Molded terminal -139 WLD2-139-N
Horizontal plunger
Screw terminals
(Conduit size: G
1
/2)
Heat-resistant type
2.8 mm max.
WLSD-TH-N
Cold-resistant type WLSD-TC-N
Corrosion-resistant type WLSD-RP-N
Direct-wire cable
Coolant-resistant type WLSD-RP60-N
Molded terminal -139 WLSD-139-N
Horizontal-roller plunger
Screw terminals
(Conduit size: G
1
/2)
Heat-resistant type WLSD2-TH-N
Cold-resistant type WLSD2-TC-N
Corrosion-resistant type WLSD2-RP-N
Direct-wire cable
Coolant-resistant type WLSD2-RP60-N
Molded terminal -139 WLSD2-139-N
Molded terminal -140 WLSD2-140-N
+2°
-1°
+2°
-1°
+2°
-1°
+2°
-1°
