on networks N300RE User Manual

Supplemental Information
28
N300RE WiFi Range Extender
Factory Settings
 To return the extender to its factory settings
Use a paperclip to press and hold the Factory Set
tings button on the side panel for 7
seconds.
The extender resets, and returns to its factory settings.
Factory Settings
Smart Wizard Enabled
Wireless Wireless communication Enabled
Wireless network name (SSID) On_Networks_EXT
Security Disabled
Transmission speed Auto
*
*. Maximum wireless signal rate (IEEE Standard 802.11). Actual throughput will vary. Network conditions and
environmental factors, including volume of network traffic, building materials and construction, and network
overhead, lower actual data throughput rate.
Country/Region United States (varies by region)
Operating mode 802.11n, 802.11g, 802.11b
Data rate Up to 300 Mbps
Technical Specifications
Technical Specifications
Network protocol and
st
andards compatibility
Data and Routing Protocols: TCP/IP, DHCP server and client
AC input 100-240V~, 0.3A (Max)
Physical specifications • Dimensi
ons: 112 x 74 x 45 mm (4.41 x 2.91 x 1.77 in)
• W
eight: 0.245 kg (0.54 lb)
Environmental • Ope
rating temperature: 32° to 140° F (0° to 40° C)
• Ope
rating humidity: 90% maximum relative humidity, noncondensing
• Electro
magnetic emissions: Meets requirements of: FCC Part 15 Class B.
Interface • Local: 10BASE-T
, 100BASE-Tx, RJ-45
• 802.1
1n/g/b

on networks N300RE Specifications

General

Type	-
Maximum transfer distance	- m
Windows operating systems supported	Yes
Product color	White
Bandwidth	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPS
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi data rate (max)	300 Mbit/s
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	45 mm
Width	74 mm
Height	112 mm
Weight	245 g
