35
R3, R5, R6, R26,
R27, R32,R44, R46,
R48, R49, R50,
Resistor, ±1%,
0.063W
0402 ERJ-2RKF68R0X,
ERJ-2RKF68R0X,
ERJ-2RKF68R0X,
ERJ-2GE0R00X,
ERJ-2GE0R00X,
ERJ-2GE0R00X,
ERJ-2GEJ103X,
ERJ-2GEJ103X,
ERJ-2GEJ103X,
ERJ-2GE0R00X,
ERJ-2GE0R00X,
ERJ-2GE0R00X,
ERJ-2GE0R00X,
ERJ-2GE0R00X,
ERJ-2GEJ103X
P68.0LCT-ND, P68.0LCT-ND,
P68.0LCT-ND,
P0.0JCT-ND, P0.0JCT-ND,
173-8862,
P10KJCT-ND, P10KJCT-ND,
P10KJCT-ND,
173-8862, 173-8862,
173-8862,
173-8862, 173-8862,
P10KJCT-ND
R7, R36, R40,
R41,R42, R43, R51
Resistor, ±1%, 0.1W 0402 ERJ-2GEJ103X P10KJCT-ND
R10, R11 Resistor, ±1%, 0.1W 0402 ERJ-2RKF39R0X P39.0LCT-ND
R12, R13, R14, R20 Resistor, ±1%, 0.1W 0402 ERJ-2RKF4701X P4.70KLCT-ND
R15, R16 Resistor, ±1%, 0.1W 0402 ERJ-2RKF2200X P220LCT-ND
R17, R18, R19, R29 Resistor, ±1%, 0.1W 0402 ERJ-2RKF6801X P6.80KLCT-ND
R21, R45, R47,
R52, R53
Resistor, ±1%, 0.1W 0402 ERJ-2GE0R00X P0.0JCT-ND
R22, R23, R24,
R25, R28
Resistor, ±1%, 0.1W 0402 ERJ-2RKF1500X 173-8862
R54 Resistor, ±1%, 0.1W 0402 ERJ-2RKF1003X P100KLCT-ND
SW1, SW2 ALPS -
SKHUALE010 -
Ta ct i le S wi tc h,
SPNO, SMD,
6.5x6.2x2.5mm
ALPS_SKHUxxx010_WO_GND SKHUALE010 35-790-00
U1 RSL10 QFN
U2 IC MCU 32bit 128kB
flash 100LQFP
LQFP-100 ATSAM3U2CA-AU ATSAM3U2CA-AU-ND
U3 IC REG LIN 3.3V
600MA 5TSOP
TSOP-5IPC NCP114ASN330T1G NCP114ASN330T1GOSCT-ND
U4 TRANSLATOR
LEVEL 4BIT
14-TSSOP
TSOP65P640X120-14N NLSX5014DTR2G NLSX5014DTR2GOSCT-ND
U5 Remote 16-bit
expander
QFN50P400X400 PCA9655EMTTXG PCA9655EMTTXGOSDKR-ND
X1 ECS 48MHz Crystal XTAL 4 pads ECS-480-8-47-JTN-TR XC1969CT-ND
X2 EPSON TOYOCOM
- FC-135
32.768KHZ ±20PPM
XTAL_3215 FC-135 32.768KHZ
±20PPM
FC-135 32.7680KA-AC-ND
X3 XTAL SMD 3225,
12MHz, 18pF,
±30ppm
BT-XTAL_3225 7M-12.000MAAJ-T 887-1121-1-ND
Table 13. Bill of Materials for RSL10 QFN Evaluation and Development Board Version 1.3 (Continued)
Designator Description Footprint Doc
Manufacturer Part
Number
Supplier part number
