NOTE: Designators C2, C3, C4, C5, C6 and R3, R5, R6, R26, R27, R32,R44, R46, R48, R49, R50 are
not populated
See Jumper
Location
CONN JUMPER
SHORTING GOLD
FLASH
CONN JUMPER (2.54mm)
Gold
SPC02SYAN S9001-ND
See Installation MACHINE SCREW
PAN PHILLIPS 4-40
n/a NY PMS 440 0025 PH H542-ND
See Installation HEX STANDOFF
4-40 NYLON 3/8”
n/a 1902B 36-1902B-ND
Table 13. Bill of Materials for RSL10 QFN Evaluation and Development Board Version 1.3 (Continued)
Designator Description Footprint Doc
Manufacturer Part
Number
Supplier part number
