GENERAL
INFORMATION
The BF welder is a complete engine driven, alter-
nating current arc welding machine. It consists of a
two-cylinder gasoline engine directly connected to
an electric generator and mounted to a sturdy
carrying frame. The welder controls and AC output
receptacles are located in the control box that is
mounted on the generatorend ofthe unit. An optional
two-wheeled dolly is available if the unit must be
moved frequently.
WARNING
This symbol is used throughout the manual to
warn of possible personal injury.
[ CAUTION j
Th
'
s
symbol refers to possible unit damage.
The welder is rated 180 amperes, 25 volts, alternating
current at 50% duty cycle. Auxiliary alternating
current is available and output is 120 volts or 120/240
volts,
rated 5000 watts, 60 hertz at 100% duty cycle.
AC output is available at any time although at reduced
output when the welding current is being used. This
AC output is convenient for emergency lighting,
running power tools, etc., when working at locations
away from AC power line sources.
When instructions in this manual refer to a specific
model of welder, identify the model by referring to the
model and specification designation as shown on the
unit nameplate.
How to interpret model and specification number.
Before operating any welder, become thoroughly
familiar with the safety precautions that follow!
5.0 BF - 341 E / 1 A
4 5
1.
Indicates Kilowatt rating and factory code for
general identification.
2.
Factory code for AC voltage output: code 341
indicates 120 volts, AC; 343 indicates 120/240
volts,
AC.
3. Specific type: E - Electric starting at welder only.
4.
Factory code for optional equipment supplied.
5. Specification letter advances with factory
production modification.
