54
MAINTENANCE AND REPAIR
ASSEMBLY ·TORQUES
Assembly torques as given here require the use of a torque wrench.
,These assembly torques. will assure proper tightness without danger of
stripping the threads. If a torque wrench is not available, you will have
to estimate the degree of tightness necessary for the stud, nut or screw
being installed and tighten accordingly. Be carefut not to strip the
threads. Check all studs, nuts and screws often. Tighten as needed to
prevent them from working loose.
LB.
FT. TORQUE
Cyliiider Head
Capscrews ....•..............• 25 to 30
Rear Bearing Plate Nuts •...•.............••. 18 to 20
Connecting Rod Bolts ....... , ............•.•.
29 to :H
Flywheel Capscrew .......................... . 40 to 45
Armature thru Stud and Nut ...•............•..
45
to 50
Other 5/16 inch Cylinder Block. Studs and Nuts .•
10 to 12
ENGINE
CARBURETOR. -
CarbUretor maintenance should consist of regular
cleaning. Some types of gasoline have a tendency to-
ward formation 01 gum deposits inside the carburetor. This gum for-
maHon can usually be removed by soaking in alcohol or acetone. A fine
wire may be used to clean jets.
the float is not damaged. If necessary to reset the f1oan~vel,
a small screw drlv-er to bend the lip of the float, With the,carbure-
toi: casting inverted and the float resting llghtly against the needle in its
. seat, clearance between the bowl cover gasket and the free end of the
float should be 5/16"(7/32" ifa "DAY" reservoir tank is used) •
.
Carburetor adjustments appear inthe ADJUSTMENT section herein. Be
slire the throttle assembly works freely. When reinstalling adjusting
needles, do not force them into their seats.
MAGNETO STATOR INSTALLATION . .., The magneto stator assembly
is mounted on the gear cover
andtheflywheel must be removed to expose it. ThE? st::tl~r has 2 pairs
of mounting hales. The innermost holes give 19
0
spark advance as re-
quir~d for engines with speed range of 1500to,2490.rpm.The outer-
most holes give 25
0
spark advance asrequir, '~,?engineswith speed
range of 2500 rpm and above.ConnectJhe 8r coil lead (ground)
to the stator mounting screw .Connectth~ ~t,C)r larger lead to the
insulated terminal on the blower housingw oconnectslo the
ignition coil andbreakerpoints.BestJl'(Jthe er lead is heldin
place to prevent rubbing on the flywheel. . .
