Before installing, check the pinion clearance. Proper
clearance is important to ensure starter engagement.
Press on solenoid core to shift the pinion into full
mesh and measure the clearance between pinion and
pinion stop, Figure 47. This should be between 0.07-
inch and 0.12-inch
(3.05
mm) (as near to 0.070-inch
[1.78 mml as possible.) Adjust the link screw on the
end of the solenoid plunger for proper clearance.
PUSH
PLUNGER
STOP
i
STARTING MOTOR NEED
NOT BE REMOVED FROM
ENGINE TO MAKE
THIS
MEASUREMENT
'
(0.07"-0.19"
CLEARANCE.
SEE TEXT)
FIGURE 47. PINION CLEARANCE
MlTSUBlSHl STARTER REMOVAL
AND INSTALLATION
1.
Remove both battery cables from battery. Dis-
2.
Disconnect battery cable and electrical lead wires
3.
Remove capscrews and flat washers that attach
4.
Remove starter.
5.
Mount starter motor to engine by a direct reversal
of
the removal procedure. Connect battery cable
and wires to starter..
6.
Connect battery cables to battery. Connect
ground cable last.
connect ground cable first.
from starter.
starter to mounting bracket.
MlTSUBlSHl STARTER DISASSEMBLY
1.
Remove
M
terminal nut and wire lead from
2.
Remove the two solenoid mounting screws and
solenoid.
remove solenoid.
3.
Remove the two through bolts and brush holder
retaining screws. Remove rear bracket (Figure
47a).
THROUGH
BOLTS
%
ES-1186
FIGURE 47a. REMOVING REAR BRACKET
4.
Remove frame assembly, and brush holderassem-
bly while pulling the brushes upward. Then re-
move armature assembly.
5.
Remove cover assembly, (snap ring and washer)
from the pinion shaft (Figure 47b).
COVER
d
ES-1195
SNAP
RING
FIGURE 47b. REMOVING SNAP RING AND WASHER
6.
Remove capscrew that secures center bracket to
front bracket. Remove the center bracket; several
washers used to adjust pinion shaft end play can
now be removed (Figure 47c).
CENTER
BRACKET
WASHERS
CAPSCREW
ES-1187
FIGURE 47c. REMOVING CENTER BRACKET
44
