Onkyo A-9050 Service Manual

A-9050
Exploded Views - 3
A
1
2
3
4
5
B C D
U0011
U0030
A102
A101
A001
U0015
U0013
T901
U0014
U0010
U0016
A012
A011
A010
838430088GR
Other Screws:
3TTB+8B(3BC)
A013
A015 x 5PCS.
Q526
Q524
Q528
Q525
D900
Q523
Q527
Q529
A020 x 4PCS.
A020
x 4PCS.
x 2PCS.
A111
x 2PCS.
A005
x 7PCS.
A003
x 4PCS.
A002
x 4PCS.
Q530
Q527A,Q528A,Q529A,Q530A

Onkyo A-9050 Specifications

General

Output level	175 mV
Damping factor	60
Amplifier class	A
Output impedance	2200 Ω
Audio output channels	2.0 channels
Peak power per channel	75 W
Signal-to-Noise Ratio (SNR)	110 dB
Total Harmonic Distortion (THD)	0.08 %
AC (power) in	Yes
Audio (L/R) in	5
Audio (L/R) out	1
Digital audio coaxial in	2
Speakers connectivity type	RCA
Purpose	Home
Product color	Silver
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	160 W
Package weight	10500 g

Weight and Dimensions

Depth	330.3 mm
Width	435 mm
Height	139 mm
Weight	820 g
