Onkyo BD-SP807

15
CONNECTIONS
EN
When using HDMI connections make “HDMI Audio Out” setting in “Audio” menu according to the specifications of the
device to be connected. Refer to page 42.
S Audio signals output from HDMI OUT jack
*1
Full decoded.
*2
Only the independent substream is decoded.
*3
Dolby TrueHD stream is decoded.
*4
Only the Dolby Digital substream is decoded.
*5
Only the core substream is decoded.
*6
When audio source is Multi-channel, decoded as 7.1ch. However, number of the output audio channel will depend on
the number of the connected speakers.
HDMI Audio Setting
Device to be connected “HDMI Audio Out” setting Output HDMI audio signal
Device compatible with Dolby Digital, Dolby
Digital Plus, Dolby TrueHD, DTS or DTS-HD
decoding
HDMI Multi(Normal)
Dolby Digital, Dolby Digital Plus, Dolby TrueHD,
DTS, or DTS-HD bitstream are output from
HDMI OUT jack. Make the speaker settings on
the connected AV amplifier, etc.
Device compatible with 3 or more channels of
audio inputs (not Dolby Digital, Dolby Digital
Plus, Dolby TrueHD, DTS or DTS-HD compatible)
HDMI Multi(LPCM)
Multi-channel audio signals are output from
HDMI OUT jack. Make the speaker settings with
the speaker setting items appear after you
select “HDMI Multi(LPCM)”. Refer to page 42.
Device compatible with 2-channel audio input
or device not compatible with audio input
HDMI 2ch
Down-mixed 2-channel audio signals are
output from HDMI OUT jack.
HDMI connection to a TV, and digital audio
connection (coaxial/optical) to an AV amplifier
Audio Mute
HDMI audio will be muted, and Dolby Digital /
DTS bitstream or LPCM will be output from
AUDIO OUTPUT (DIGITAL OPTICAL/COAXIAL)
jacks depending on “Digital Out” setting. Refer
to page 43.
“HDMI Audio Out”
setting
A
“HDMI Multi(Normal)” “HDMI Multi(LPCM)” “HDMI 2ch”
“BD Audio Mode”
setting
A
“HD Audio
Output”
“Mix Audio
Output”
“HD Audio
Output”
“Mix Audio
Output”
“HD Audio
Output”
“Mix Audio
Output”
Media
ª
Audio Source
ª
Which audio format can be output depends on the compatibility of the connected device.
BD-video
Dolby Digital Dolby Digital Dolby Digital Multi PCM Multi PCM
Downmix
2ch PCM
Downmix
2ch PCM
Dolby Digital Plus
Dolby Digital
Plus
Dolby Digital Multi PCM
*1
Multi PCM
*2
Downmix
2ch PCM
*1
Downmix
2ch PCM
*2
Dolby TrueHD Dolby TrueHD Dolby Digital Multi PCM
*3
Multi PCM
*4
Downmix
2ch PCM
*3
Downmix
2ch PCM
*4
DTS DTS DTS Multi PCM
*6
Multi PCM
*6
Downmix
2ch PCM
Downmix
2ch PCM
DTS-HD DTS-HD DTS Multi PCM
*1, 6
Multi PCM
*5, 6
Downmix
2ch PCM
*1
Downmix
2ch PCM
*5
LPCM Multi LPCM Multi PCM Multi PCM Multi PCM
Downmix
2ch PCM
Downmix
2ch PCM
AVCHD
Dolby Digital Dolby Digital Multi PCM Downmix 2ch PCM
LPCM Multi PCM Multi PCM Downmix 2ch PCM
DVD-video
Dolby Digital Dolby Digital Multi PCM Downmix 2ch PCM
DTS DTS Multi PCM Downmix 2ch PCM
LPCM 2ch PCM 2ch PCM 2ch PCM
MPEG MPEG Multi PCM Downmix 2ch PCM
Audio CD /
MP3
PCM 2ch PCM 2ch PCM 2ch PCM
DivX
®
Dolby Digital Dolby Digital Multi PCM Downmix 2ch PCM
PCM 2ch PCM 2ch PCM 2ch PCM
DTS-CD DTS DTS Multi PCM Downmix 2ch PCM
