Onkyo CR-N7 User Manual

13
Disc Notes—Continued
• The following ID3 tags are supported: versions
1.0/1.1 and 2.2/2.3/2.4. Versions 2.5 and later are not
supported. Normally, version 2.2/2.3/2.4 tags have
priority and will be displayed regardless of the ID3
VER 1 preference on page 32.
• For ID3 version 2 tags, the tag information recognized
will be those embedded in the beginning of the file.
We recommend that you include only title, artist
name, and album name information in ID3 tags. Com-
pressed, encrypted, and unsynchronized ID3 tags can-
not be displayed.
Notes:
• With CD-ROM, CD-R, and CD-RW discs that contain
many files and folders, and files other than MP3s, it
may take a long time to read the disc. We recommend
that you include only MP3 files on your discs, use
about 20 folders, and limit folder nesting to three lev-
els deep.
• In this manual, MP3 files are referred to as tracks.
Also, folders (directories) are referred to as groups.
Disc Content Organization
■ CD
CDs contain tracks.
■ MP3
MP3 discs contain MP3 tracks organized into groups.
Handling Discs
• Never touch the underside of a disc. Always hold discs
by the edge, as shown.
• Never attach adhesive tape or sticky labels to discs.
Cleaning Discs
• For best results, keep your discs clean. Fingerprints
and dust can affect the sound quality and should be
removed as follows. Using a clean soft cloth, wipe
from the center outwards, as shown. Never wipe in a
circular direction.
• To remove stubborn dust or dirt, wipe the disc with a
damp soft cloth, and then dry it with a dry cloth.
• Never use solvent-based cleaning fluids, such as thin-
ner or benzine, commercially available cleaners, or
antistatic sprays intended for vinyl records, because
they may damage the disc.
Storing Discs
• Don’t store discs in places subject to direct sunlight,
or near heat sources.
• Don’t store discs in places subject to moisture or dust,
such as in a bathroom or near a humidifier.
• Always store discs in their cases and vertically. Stack-
ing, or putting objects on unprotected discs may cause
warping, scratches, or other damage.
Track 2 Track 3 Track 4Track 1
Audio CD
Track 5
Group 1
Group 2
Track 2 Track 3 Track 1Track 1 Track 2
MP3 (CD-R/CD-RW)
Underside
✔

Onkyo CR-N7 Specifications

Power

power supply	AC 230–240 V, 50 Hz
power consumption	68 W
stand-by power consumption	0.3 W

Audio Inputs and Outputs

analog inputs	LINE, TAPE, HDD
digital outputs	Optical: 1
analog outputs	TAPE, HDD

Amplifier Specifications

power output	14 W + 14 W (8 Ω, 40 Hz–20 kHz THD, 0.4%)
dynamic power	26 W + 26 W (4 Ω, JEITA)
damping factor	25 (8 Ω)

Tuner Specifications

fm tuning frequency range	87.5 MHz–108 MHz
am tuning frequency range	522 kHz–1611 kHz
stereo separation	40 dB (1 kHz)

CD Specifications

frequency response	10 Hz–20 kHz
audio dynamic range	92 dB
thd (total harmonic distortion)	0.009 %

Weight and Dimensions

dimensions	205 W x 147 H x 356 D mm
weight	4.3 kg
