5
Before Using This Unit
Notes:
• If the remote controller doesn’t work reliably, try
replacing the batteries.
• Don’t mix new and old batteries or different types of
batteries.
• If you intend not to use the remote controller for a long
time, remove the batteries to prevent damage from
leakage or corrosion.
• Expired batteries should be removed as soon as possi-
ble to prevent damage from leakage or corrosion.
To use the remote controller, point it at the CD receiver’s
remote control sensor, as shown below.
Notes:
• The remote controller may not work reliably if the CD
receiver is subjected to bright light, such as direct sun-
light or inverter-type fluorescent lights. Keep this in
mind when installing.
• If another remote controller of the same type is used
in the same room, or the CD receiver is installed close
to equipment that uses infrared rays, the remote con-
troller may not work reliably.
• Don’t put anything, such as a book, on the remote con-
troller, because the buttons may be pressed inadvert-
ently, thereby draining the batteries.
• The remote controller may not work reliably if the CD
receiver is installed in a rack behind colored glass
doors. Keep this in mind when installing.
• The remote controller will not work if there’s an
obstacle between it and the CD receiver’s remote con-
trol sensor.
Installing the Batteries
1
Detach the battery cover by pressing the
tab and pulling up the cover.
2
Insert two AA-size batteries into the bat-
tery compartment.
Carefully follow the polarity diagram (positive +
and negative - symbols) inside the battery com-
partment.
3
After batteries are installed and seated
correctly, attach the compartment cover.
Using the Remote Controller
Approx. 5 m
(16 ft.)
Remote control sensor
CD receiver
To Next Page
