Onkyo CR-N7 User Manual

35
Programming Radio Stations—Continued
Note:
• If the FM station received is an RDS station that has a
PS (Program Service Name), the frequency display
will change to the PS display. (Refer to page 39 for
more information on the RDS function.)
Customizing the Preset Channels
The following additional functions are available:
• Naming a preset channel (see page 42)
• Erasing a preset channel (see page 41)
• Copying the radio station in the selected channel to
another (see page 40).
If “Overwrite?” appears
The channel you’ve selected is registered
already.
• To register the new radio station by
deleting the existing radio station
Press YES/MODE.
• To cancel presetting
Press EDIT/NO/CLEAR.
If “Memory Full” appears
The FM/AM stations have already been
programmed into all 30 channels. Delete
unnecessary stations (page 41) and try
again.
7
Repeat steps 2 to 6 to preset the next
channel.
3
4, 6
2
5
1
Using the remote controller

Onkyo CR-N7 Specifications

Power

power supply	AC 230–240 V, 50 Hz
power consumption	68 W
stand-by power consumption	0.3 W

Audio Inputs and Outputs

analog inputs	LINE, TAPE, HDD
digital outputs	Optical: 1
analog outputs	TAPE, HDD

Amplifier Specifications

power output	14 W + 14 W (8 Ω, 40 Hz–20 kHz THD, 0.4%)
dynamic power	26 W + 26 W (4 Ω, JEITA)
damping factor	25 (8 Ω)

Tuner Specifications

fm tuning frequency range	87.5 MHz–108 MHz
am tuning frequency range	522 kHz–1611 kHz
stereo separation	40 dB (1 kHz)

CD Specifications

frequency response	10 Hz–20 kHz
audio dynamic range	92 dB
thd (total harmonic distortion)	0.009 %

Weight and Dimensions

dimensions	205 W x 147 H x 356 D mm
weight	4.3 kg
