Onkyo CR-N7 User Manual

55
Troubleshooting—Continued
No sound is heard from the connected device.
• Make sure that the optical digital cable is not bent or damaged.
• Set the digital output to PCM, because the CD receiver supports only PCM signals.
The turntable sounds still.
• Make sure the turntable has a built in phono equalizer.
• If the turntable has no phono equalizer built in, you must provide one separately.
Timer playback or recording does not work.
• The clock should be set correctly.
If the clock is not set, playback or recording does not work. Make sure you program the current time. (See page 44.)
• Timer operation is not activated if the power to the unit is turned on before the timer On time. Be sure to place the
unit in Standby mode before timer operation starts. (See page 51.)
• Programmed time may overlap with another timer. Be sure to set multiple timers such that time ranges do not overlap.
(See page 47.)
• If you try to set the Sleep timer or press TIMER during timer operation, the current timer setting is cancelled.
• The timer operation uses the volume level that was set before the unit was placed in Standby mode. Set an appropriate
volume level before you place the unit in Standby mode. (See page 51.)
• Make sure that the cable and analog audio cables are connected correctly.
• If you selected an external Onkyo CD recorder for the timer operation, you must specify the source name.
(See page 20.)
Time display is not visible during Standby mode.
• Turn the current time display on while the unit is in Standby mode. (See page 46.)
• Locate the speakers far from the TV.
Timer Function
The Colors of the TV Picture Bleed.
Onkyo is not responsible for damages (such as CD rental fees) due to unsuccessful recordings caused by unit’s mal-
function.
Before you record important data, make sure that the material will be recorded correctly.
This product uses a microcomputer to perform various advanced functions. However, noise, radio interference, or
static electricity could occasionally cause the unit to malfunction. In this case, unplug the power cable from the AC
outlet, then plug it in again in five seconds.

Onkyo CR-N7 Specifications

Power

power supply	AC 230–240 V, 50 Hz
power consumption	68 W
stand-by power consumption	0.3 W

Audio Inputs and Outputs

analog inputs	LINE, TAPE, HDD
digital outputs	Optical: 1
analog outputs	TAPE, HDD

Amplifier Specifications

power output	14 W + 14 W (8 Ω, 40 Hz–20 kHz THD, 0.4%)
dynamic power	26 W + 26 W (4 Ω, JEITA)
damping factor	25 (8 Ω)

Tuner Specifications

fm tuning frequency range	87.5 MHz–108 MHz
am tuning frequency range	522 kHz–1611 kHz
stereo separation	40 dB (1 kHz)

CD Specifications

frequency response	10 Hz–20 kHz
audio dynamic range	92 dB
thd (total harmonic distortion)	0.009 %

Weight and Dimensions

dimensions	205 W x 147 H x 356 D mm
weight	4.3 kg
